功能點Feature and functions
●燃氣燙平機系列采用蒸汽加熱，傳動采用變頻調速， 根據加熱溫度和織物厚度隨意調節速度。
●在輥筒采用不銹鋼制造，表面經過磨削加工處理使用織物磨損降到。
●運行可靠，采用減速器聯接皮帶輪及鏈輪傳動，并配置傳動漲緊機構，運行速度。
●副輥采用噴鋅處理，搞腐蝕能力強，經久耐用。
●Three rolls irons out machine uses the steam heating the transmission uses the frequency conversion velocity modulation according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the high quality stainless steel manufacture the surface reduces lowly to after the abrasive machining processing use fabric attrition.
●The movement is reliable uses the reduction gear joint belt pulley and the sprocket feed and disposes the transmission to rise the tight organization the guarantee running rate.
●All vice-rollers use spurt zinc processing does corrosion ability durable.
●燃氣燙平機系列采用蒸汽加熱，傳動采用變頻調速， 根據加熱溫度和織物厚度隨意調節速度。
●在輥筒采用不銹鋼制造，表面經過磨削加工處理使用織物磨損降到。
●運行可靠，采用減速器聯接皮帶輪及鏈輪傳動，并配置傳動漲緊機構，運行速度。
●副輥采用噴鋅處理，搞腐蝕能力強，經久耐用。
●Three rolls irons out machine uses the steam heating the transmission uses the frequency conversion velocity modulation according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the high quality stainless steel manufacture the surface reduces lowly to after the abrasive machining processing use fabric attrition.
●The movement is reliable uses the reduction gear joint belt pulley and the sprocket feed and disposes the transmission to rise the tight organization the guarantee running rate.
●All vice-rollers use spurt zinc processing does corrosion ability durable.
技術參數Technical parameters
|
型號 model 項目 item |
QZPⅡ 2500 |
QZPⅡ2800 |
QZPⅡ 3000 |
QZPⅡ 3300 |
|
| 熨平寬 | Biggest ironing width | 2500 | 2800 | 3000 | 3300 |
| 熨平速度(m/min) | Ironing speed | 3-20 | 3-20 | 3-20 | 3-20 |
| 加熱溫度(℃) | Highest heating temperature | 158 | 158 | 158 | 158 |
| 燃氣壓力(MPA) | Steam pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| 燃氣耗量(kg/h) | Steam consumption | 300 | 350 | 380 | 400 |
| 電機功率(KW) | Motor power | 2.2 | 2.2 | 2.2 | 2.2 |
| 額定電壓(V) | Rated voltage | 380 | 380 | 380 | 380 |
| 外形(長×寬×)(mm) |
Dimension (L×W×H） |
3700× 3100× 1385 |
4000× 3100× 1385 |
4200× 3100× 1385 |
4400× 3100× 1385 |
| 整機重量 | Machine weight | 3300 | 3500 | 3800 |
4000 |
